Ares X1-Gear Drive

Product

{"table-data":"{ \"rows\": [ { \"type\": \"head\", \"key\": \"model\", \"values\": [ \"Ares X1-Gear Drive\" ] }, { \"type\": \"head\", \"key\": \"PERFORMANCE\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Top Speed\", \"values\": [ \"60kph\/37mph(By 200mm wheel)\" ] }, { \"type\": \"property\", \"key\": \"Range\", \"values\": [ \"Up to 55km\/35miles\" ] }, { \"type\": \"property\", \"key\": \"Hill\", \"values\": [ \"46%\" ] }, { \"type\": \"property\", \"key\": \"Max Load\", \"values\": [ \"200kg\" ] }, { \"type\": \"head\", \"key\": \"POWER AND BATTERY\", \"values\": [] }, { \"type\": \"property\", \"key\": \"FOC-ESC\", \"values\": [ \"90A\" ] }, { \"type\": \"property\", \"key\": \"Motor\", \"values\": [ \"6384 150KV\" ] }, { \"type\": \"property\", \"key\": \"Motor Peak Power\", \"values\": [ \"3500w×2\" ] }, { \"type\": \"property\", \"key\": \"Pole pair\", \"values\": [ \"7\" ] }, { \"type\": \"property\", \"key\": \"Battery\", \"values\": [ \"14S4P Samsung 40T\" ] }, { \"type\": \"property\", \"key\": \"Battery Capacity\", \"values\": [ \"16Ah\/ 828Wh\" ] }, { \"type\": \"property\", \"key\": \"Temperature Comfort Zone\", \"values\": [ \"-20°C~45°C\" ] }, { \"type\": \"property\", \"key\": \"Torque\", \"values\": [ \"65 N·m\" ] }, { \"type\": \"head\", \"key\": \"CHARGING\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Charger Output\", \"values\": [ \"58.8V 4A\" ] }, { \"type\": \"property\", \"key\": \"Charger Input\", \"values\": [ \"AC 110V-240V~50\/60Hz Max 3.0A\" ] }, { \"type\": \"property\", \"key\": \"Charge Time\", \"values\": [ \"4-5h\" ] }, { \"type\": \"property\", \"key\": \"6A Charge Time\", \"values\": [ \"2.5h\" ] }, { \"type\": \"property\", \"key\": \"Remote Charging Input\", \"values\": [ \"5V 1A\" ] }, { \"type\": \"head\", \"key\": \"DRIVE SYSTEM\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Drive Mode\", \"values\": [ \"Gear Drive\" ] }, { \"type\": \"property\", \"key\": \"Gear Ratio\", \"values\": [ \"4.3\" ] }, { \"type\": \"head\", \"key\": \"TRUCK\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Truck\", \"values\": [ \"Precision TKP Trucks 350mm\/13.8 inches wide\" ] }, { \"type\": \"property\", \"key\": \"Bushing Durometer\", \"values\": [ \"95A\" ] }, { \"type\": \"head\", \"key\": \"WHEELS\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Wheels\", \"values\": [ \"AT 7 inches(180×65mm)Tires\" ] }, { \"type\": \"property\", \"key\": \"Wheel Range\", \"values\": [ \"160-200mm\" ] }, { \"type\": \"property\", \"key\": \"Psi\", \"values\": [ \"25-40\" ] }, { \"type\": \"head\", \"key\": \"DIMENSIONS\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Board size\", \"values\": [ \"1180mm×370mm×200mm\" ] }, { \"type\": \"property\", \"key\": \"Deck size\", \"values\": [ \"1030mm×267mm\" ] } ]}"}
{"table-data":"{ \"rows\": [ { \"type\": \"property\", \"key\": \"Weight\", \"values\": [ \"17kg\/ 37.7lbs\" ] }, { \"type\": \"property\", \"key\": \"Wheelbase\", \"values\": [ \"1000mm\" ] }, { \"type\": \"head\", \"key\": \"DECK MATERIALS\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Deck Materials\", \"values\": [ \"Premium T700 3K Carbon Fiber\" ] }, { \"type\": \"head\", \"key\": \"WATER PROOF\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Water Proof\", \"values\": [ \"IP65\" ] }, { \"type\": \"head\", \"key\": \"SPEED MODE\", \"values\": [] }, { \"type\": \"property\", \"key\": \"Low\", \"values\": [ \"10-20Km\/h\" ] }, { \"type\": \"property\", \"key\": \"Eco\", \"values\": [ \"25-35Km\/h\" ] }, { \"type\": \"property\", \"key\": \"Sport\", \"values\": [ \"35-45Km\/h\" ] }, { \"type\": \"property\", \"key\": \"Sport+\", \"values\": [ \"45-55Km\/h(By 180mm wheel)\" ] } ]}"}

x1-specs

NOTES

* Tested by 65kg rider on flat and smooth road. And top speed decreases as weight goes up
* When the battery is not full, the max speed will drop.
* Customers can adjust the max speed, torque and braking of each speed mode on remote.
*Top speed also can be increased by larger wheel.
