Ares X3 GEAR
Order

120A

ESC

3500W*2

Peak Power

60KM/h

Top Speed

Acedeck® Ares X3 GEAR Electric Skateboard

Acedeck® Ares X3 GEAR

A high-performance street board,
for the street wheel purists, and the pros

Acedeck is excited to introduce our latest board designed specifically for street-wheel lovers, the Ares X3 GEAR. It still has the incredible characteristics of the X3, such as amazing free rolling ability, and great compatibility with all street wheels, but with much better acceleration and braking performance, and improved reliability and clearance.
Acedeck® Ares X3 GEAR

Street Wheel Experience.

Just like for the X3, the most important aspect of the X3 GEAR is an optimal street wheel riding experience.

This time the X3 GEAR is fitted with gear drives instead of direct drives. The Street ELEMENT Gear Drive system has comparable free-roll ability to the previously used Direct Drive system.

By default, it comes with Kegel and ABEC adapters, making it easy for riders to swap between their favorite urethane wheels, of any size. And to compliment that, the board is fitted with the acclaimed and loved 105mm MAD Wheelz V2 urethane wheels.

Acedeck® Ares X3 GEAR

Performance and Range.

The 2WD Street ELEMENT system, paired with the 170KV motors and a 120A ESC, is able to provide a lot more torque and overall performance, especially in acceleration and braking, compared to the 4WD Direct Drive system.

The battery has also been upgraded, now fitted with Samsung 50S cells, in a 14S3P configuration, which adds up to a total of 777Wh. The Samsung 50S cells are considered one of the best cells on the market, because of its impressive performance and efficiency, while also being a high-capacity cell.

170 KV

Motors

120 A

Customized ESC

777 Wh

Battery Capacity

Deck and Compact Size

The X3 Gear shines not only as a performance board but also as an every day board, due to its compact design and portability. Inspired by downhill boards, the deck is not too long, yet is made to adapt to various rider stances, feet placement, and comfort.

It is an improved and reinforced version of the previous X3 deck, made out of premium carbon fiber, to make sure it is as lightweight as possible.

Split-angle

It also keeps the split-angle technology, for a more locked rear truck and a more open front end, with +5º and -5º at the front and rear. The higher angle of the front truck allows for greater agility and easier turning, which is especially useful for making sharp turns. The lower angle of the rear truck provides better stability, especially at high speeds, reducing wobbling and making it easier to maintain a straight line.

The split angle design helps the board absorb ground vibrations more effectively, providing a smoother ride, particularly on rough surfaces.
±5o
Split-Angle Technology
Acedeck® Ares X3 GEAR
And to make the X3 Gear even more special, this time the deck is coated in a beautiful white finish.
Acedeck® Ares X3 GEAR

CNC Machined

As always at Acedeck, we only use CNC machined aluminum everywhere we can, from the trucks and ESC cover, to the wheel hubs and gear drives on all our boards.

Compared to cast or forged aluminum elements found on most boards, our precision machined parts made out of 6061 aluminum are much more durable, and offer better turning performance and stability when it comes to our TKP Precision trucks, for example.
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard
Acedeck® Ares X3 GEAR Electric Skateboard

Acedeck® Ares X3 GEAR Electric Skateboard

A high-performance street board, for the street wheel purists, and the pros.

The Ares X3 GEAR is a very powerful board with great range, in a compact and slim carbon fiber platform. This is one of the most powerful street wheel board you can buy.

  • 120A ESC, 6374 170kv motors, paired with Samsung 50S battery
  • Up to 37 mph top speed / 31 mile range
  • Both Kegel and ABEC adapters are included, allowing you to easily swap to your favorite urethane wheels.
  • CNC precision trucks for maximum stability and control
  • Unique carbon fiber unibody with special reinforcement .Compact and portable. Your next powerful everyday commuting board.
  • Split angle deck: allows for easier turning, better stability, and reduced vibration
  • Comes with a CNC footstop. Don’t just ride—ride with precision, control, and a splash of personal flair.


Sale price :
Sale price$1,399.00 USD Regular price$1,699.00 USD
Save $300.00

Delivery Timeline

  • US:
    ①By Air: Estimated 12-15 Days. Start shipping from October 11th.
    ②By Sea: Estimated 30-40 Days. Start shipping from October 11th.
    ③Domestic delivery : Estimated 1-7 Days. Start shipping from November 4th.
  • EU:
    ① By Air: Estimated 12-18 Days. Start shipping from October 11th.
    ② By Sea Pro: Estimated 35-45 Days. Start shipping from October 11th.
  • Canada:
    ① Domestic Delivery: Estimated 2-8 days. Start shipping from October 31.
    ② By Air: Estimated 12-18 Days. Start shipping from October 11th.
    ③ By Sea: Estimated 50-60 Days. Start shipping from October 11th.

  • Australia:
    ① By Air: Estimated 15-18 Days. Start shipping from October 11th.
    ② By Sea: Estimated 50-70 Days. Start shipping from October 11th.
  • Other countries: Please check the delivery time on your checkout page.

Specifications

Performance

Top speed:
60kph/37mph top speed (by 105mm wheel)
Range:
Up to 50km/31 miles
Hill:
46%
Max load:
200kg

Power and Battery

FOC-ESC:
Bus current 70A
Phase current 120A
Motor:
6374 170KV
Motor power:
Rated power 3000W*2
Peak power 3500W*2
Pole pair:
7
Battery:
14S3P Samsung 50S
Battery capacity:
15Ah/ 777Wh
Temperature comfort zone:
-20°C~45°C
Torque:
45nm

Charging

Charger output:
58.8V 4A
Charger input:
AC 110V-240V~50/60Hz Max 3.0A
Standard charge time:
3-4h
350W/6A charge time:
2.5h
Remote charging input:
5V 1A

Drive System

Drive mode:
Gear drive
Gear ratio:
2.8

Truck

Truck:
Precision TKP trucks 350mm/13.8 inches wide
Axle diameter:
10mm
Bushing durometer:
Front: 95A 16mm (white)
Rear: 98A 16mm (black)

Wheels

Wheels:
105mm MAD Wheelz V2
Wheel range:
90-125mm
Pulley/Adapter:
Kegel adapter &
ABEC adapter

Dimensions

Board size:
1060mm*400m*130mm
Deck size:
940mm*240mm
Weight:
13.6kg/29.2lbs
Wheelbase:
910mm

Deck Materials

Deck materials:
Premium T700 3K
Carbon fiber

Water Proof

Water proof:
IP65

Speed Mode

Low:
15-25Km/h
ECO:
25-40Km/h
Sport:
40-50Km/h
Sport+:
50-60Km/h

FAQs

We also keep a list of questions we get asked often on our FAQ page, or feel free to contact us for more information

1. What has changed with the X3 GEAR over the previous X3?

Drive Sytem: The 4WD Direct Drive system has been replaced with a 2WD street gear drive system for better acceleration and braking performance, with similar free rolling ability, and improved clearance.

Electronics: We went from 2x 50A ESCs to a single, more powerful 120A ESC, meaning less parts to worry about. We replaced the Molicel P42A to Samsung 50S cells in the same 14S3P configuration. This means similar performance, but an extended range and capacity, from 652Wh to 777Wh. The new 170KV motors also allow of a higher top speed of 38Mph.

Wheels: Now, the board comes by default with MAD Wheelz V2 105mm wheels instead of the 95mm wheels from the X3.

Deck: The deck, while having a similar look, has been improved, reinforced and is now coated in a beautiful white finish.

Details: The board is now fitted with much better bushings, and comes with a CNC footstop included in the box for better control and foot positioning.

Reliability and Pricing: The changes from a 4WD system with 2 ESCs, to 2WD system, meant we could reduce the risk of issues overtime, but also lower the price, even though the overall performance is much stronger on the new X3 GEAR.

2. Who is it for?

The Ares X3 is made specifically for riders looking for the ultimate street wheel experience. Oftentimes, street wheel boards on the market, are budget, entry-level boards. Weak motors, small batteries, and very flexible decks that are unstable at high speed. And premium electric boards are mostly all-terrain wheels boards, or belt-driven 2-in-1. But there are many riders who wish for a premium, high-performance street wheel board, that will give them the experience of downhill riding but also uphill, with a big battery, free roll, quiet, easy wheel swap, and so on. This is exactly what the Ares X3 GEAR is. A premium, high-performance street-wheel-focused board.

It is also for riders who really love street wheels, but don’t want range anxiety. They want a longboard feel, more so than performance.

That love for street wheels is defined by the different feel they provide over big AT wheels. While AT wheels can often be described as riding on a cloud, smooth PU street wheels, give you a feeling of gliding, due to the rider being a lot closer to the ground. The rider involvement is bigger.

The compact size of the X3 GEAR also makes it a great second board to own, next to an N3 or Z3.

Overall, the Ares X3 GEAR is for a group of experienced and passionate skateboarders who value speed, performance, and range but with a strong love for the street wheel riding experience.
